Tire Specs

Tire Specs




2024

Have an FSAE question? Contact Jeff Speer or Adam Batton

2024 FSAE Ordering Information   //   Spring Rate Data  //  FSAE TTC - Force & Moment Data




SLICKS

  Item #             Size             O.D.    Tread Width   Section Width  Recom. Rim  Rim Measured   Compound   Approx. Weight  Retail S.A.E Price
43070 16.0 x 6.0-10 16.3" 6.0" 6.9" 6.0"-7.0" 6.0" R20, LCO 7 lbs. $260 $221.00
43075 16.0 x 7.5-10 16.2" 7.3" 8.4" 6.0"-8.0" 8.0" R20, LCO 8 lbs. $280 $238.00
41100 6.0/18.0-10 18.0" 6.0" 8.5" 6.0-7.0" 7.0" LC0 8 lbs $264 $224.30
43100 18.0 x 6.0-10 18.1" 6.2" 8.1" 5.5-7.0" 6.0" R20 9 lbs. $250 $212.50
43104 18.0 x 7.5-10 18.3" 7.5" 9.5" 7.0-8.0" 8.0" R20 10 lbs $270 $229.50

43164 20.5 x 7.0-13 21.0" 7.0" 8.0" 5.5-8.0" 6.0" R20 11 lbs. $310 $263.50
43167 20.0 x 7.5-13 20.6" 8.0" 9.4" 7.0-9.0" 8.0" R20 12 lbs. $340 $289.00

WETS

  Item #             Size             O.D.    Tread Width   Section Width   Recom. Rim   Rim Measured   Compound   Approx. Weight  Retail S.A.E. Price
44070 16.0 x 7.0-10 16.2" 7.0" 7.6" 6.0-7.0" 6.0" W3 7.5 lbs. $280 $238.43
44115 18.0 x 6.0-10 17.8" 6.2" 7.8" 6.0-8.0" 6.0" W3 9 lbs. $280 $242.24

44150 20.0 x 7.5-13 20.6" 7.4" 8.3" 7.0-8.0" 7.0" W3 12 lbs. $350 $297.55
44185 21.0 x 6.5-13 21.2" 6.7" 7.2" 6.0-8.0" 6.0" W3 11 lbs. Call for Pricing Call for Pricing

All pricing in United States Dollars (USD) effective January 1, 2024.  Pricing Listed for Domestic FSAE Teams Only.  See your local Hoosier Tire distributor for pricing outside the USA


 Catalog  Size Designation     Wheel Size   Circ.   O/A Dia.   Tread Width   Section Width   Tire Weight
SLICKS
43570 240/580R15   15 x 10 72.1" 22.9" 9.4" 10.6" 16.3 lbs.
43578 330/620R15   15 x 14 76.8" 24.4" 13.3" 15.1" 21.3 lbs.
WETS
44511 23.0x9.0R15   15 x 10 72.3" 23.0" 9.4" 10.7" 16 lbs.
44516 24.5x13.0R15   15 x 14 76.6" 24.4" 13" 15.1" 21.6 lbs.

Spring Rate Data
For more information please contact Jeff Speer.


 Catalog #   Size Designation      Wheel Size   Circ.   O/A Dia.   Tread Width   Section Width   Tire Weight
SLICKS
43164 20.5x7.0-13 R60A   13 x 6 66.2" 21.0" 6.75" 8.0" 12 lbs.
43285 22.0x8.0-13 R60A   13 x 8 69.0" 22.0" 8.0" 9.6" 14 lbs.
WETS
44185 21.0x6.5-13 W3   13 x 6 66.5" 21.2" 6.7" 7.2" 11 lbs.
44196 22.0x8.0-13 W3   13 x 8 69.0" 22.0" 7.8" 8.9" 13 lbs.

Spring Rate Data
For more information please contact Jeff Speer.


 Catalog #   Size Designation      Wheel Size   Circ.   O/A Dia.   Tread Width   Section Width   Tire Weight
SLICKS
43321 185/60R13 R60A   13 x 5.5 68.8" 21.9" 6.4" 7.7" 16 lbs.
43326 205/60R13 R60A   13 x 5.5 71.4" 22.7" 8.0" 8.7" 18 lbs.
WETS
44421 185/60R13 W3



13 x 5.5 67.5" 21.5" 6.8" 7.7" 17 lbs.
44426 205/60R13 W3   13 x 5.5 72.8" 23.1" 7.4" 8.4" 19 lbs.

Spring Rate Data
For more information please contact Jeff Speer.


 Catalog #   Size Designation     Wheel Size  Circ.   O/A Dia.   Tread Width   Section Width   Tire Weight
SLICKS
43322 185/60R13 R60A   13 x 5.5 68.8" 21.9" 6.4" 7.7" 16 lbs.
43327 205/60R13 R60A   13 x 5.5 71.4" 22.7" 8.0" 8.7" 18 lbs.
WETS
44421 185/60R13 W3   13 x 5.5 67.5" 21.5" 6.8" 7.7" 17 lbs.
44426 205/60R13 W3   13 x 5.5 72.8" 23.1" 7.4" 8.4" 19 lbs.

Spring Rate Data
For more information please contact Jeff Speer.


 Catalog #   Size Designation     Wheel Size   Circ.   O/A Dia.   Tread Width   Section Width   Tire Weight
SLICKS
46340 P185/60ZR13 SRF   13 x 5.5 68.8" 21.9" 6.4" 7.7" 16 lbs.
46350 P205/60ZR13 SRF   13 x 7.0 71.4" 22.7" 8.0" 9.1" 18 lbs.
WETS
46101 P185/65R13 W2   13 x 5.5 69.8" 22.2" 6.8" 7.9" 14.5 lbs.
46105 P205/60R13 W2   13 x 7.0 72.8" 23.1" 7.4" 8.8" 16.5 lbs.

Spring Rate Data & Base Setup Info
For more information please contact Jeff Speer.
